ADDITIONAL SMOOTHING REACTOR

Additional Smoothing Reactor is used in DC systems to reduce harmonic current and transient over current. We manufacture these devices quality raw material.

TECHNICAL DETAILS/COVERED SPECIFICATION
COVERED SPECIFICATION	EDTS 126 of Rail Coach Factory
APPLICATION	ROLLING STOCK
CONT.RATING	425 Amps
CLASS OF INSULATION	‘H’
MAX.TEMPERATURE	<90ºC
COOLING	Natural Air cooled
EQUIPMENT DESIGN TO COMPLY THE FOLLWING
TRAIN SPEED	100 KMPH
AMBIENT TEMPERATURE	-5 TO +55 DEG CEL.
HUMIDITY	UPTO 98%
COSTAL AREA	MAX.PHVALUE : 8.5 SULPHATE : 7mg/lts conductivity : 130micron/cm
VIBRATION	As per IEC
EQUIPMENT TESTED WITH THE FOLLOWING ROUTINE TEST
WINDING REGISTANCE	AS PER IS 2026
RATIO MEASEMENT/POLITRY AND PHASE RELATIONSHIP	AS PER IS 2026
RATIO MEASEMENT/POLITRY AND PHASE RELATIONSHIP	AS PER IS 2026
IMPEDENCE VOLTAGE	AS PER IS 2026
INSULATION TEST	AS PER IS 2026
